Methods to control TTL switch running on OK FPGA. More...
Inheritance diagram for ok_fpga_switch.OkFpgaTtlSwitch:
Collaboration diagram for ok_fpga_switch.OkFpgaTtlSwitch:
Public Member Functions | |
| def | __init__ (self, kwargs) |
| def | on_activate (self) |
| def | on_deactivate (self) |
| def | reset (self) |
| def | getNumberOfSwitches (self) |
| There are 8 TTL channels on the OK FPGA. More... | |
| def | getSwitchState (self, channel) |
| Gives state of switch. More... | |
| def | switchOn (self, channel) |
| def | switchOff (self, channel) |
| def | getCalibration (self, switchNumber, state) |
| def | setCalibration (self, switchNumber, state, value) |
| def | getSwitchTime (self, switchNumber) |
 Public Member Functions inherited from core.module.BaseMixin | |
| def | __init__ (self, manager, name, config=None, callbacks=None, kwargs) |
| Initialise Base class object and set up its state machine. More... | |
| def | log (self) |
| Returns a logger object. | |
| def | is_module_threaded (self) |
| Returns whether the module shall be started in a thread. | |
| def | on_activate (self) |
| Method called when module is activated. More... | |
| def | on_deactivate (self) |
| Method called when module is deactivated. More... | |
| def | getStatusVariables (self) |
| Return a dict of variable names and their content representing the module state for saving. More... | |
| def | setStatusVariables (self, variableDict) |
| Give a module a dict of variable names and their content representing the module state. More... | |
| def | getConfiguration (self) |
| Return the configration dictionary for this module. More... | |
| def | get_connector (self, connector_name) |
| Return module connected to the given named connector. More... | |
| Public Member Functions inherited from core.module.ModuleMeta | |
| def | __new__ (cls, name, bases, attrs) |
| Collect declared Connectors, ConfigOptions and StatusVars into dictionaries. More... | |
Public Attributes | |
| lock | |
| fp | |
| Public Attributes inherited from core.module.BaseMixin | |
| module_state | |
| connectors | |
Detailed Description
Methods to control TTL switch running on OK FPGA.
Example config for copy-paste:
fpga_ok_switch: module 'switches.ok_fpga.ok_fpga_switch.OkFpgaTtlSwitch'
Member Function Documentation
◆ getNumberOfSwitches()
| def ok_fpga_switch.OkFpgaTtlSwitch.getNumberOfSwitches | ( | self | ) |
There are 8 TTL channels on the OK FPGA.
Chan PIN
Ch1 D10 Ch2 D15 Ch3 C7 Ch4 B12 Ch5 B16 Ch6 B14 Ch7 C17 Ch8 C13
- Returns
- int: number of switches
◆ getSwitchState()
| def ok_fpga_switch.OkFpgaTtlSwitch.getSwitchState | ( | self, | |
| channel | |||
| ) |
Gives state of switch.
- Parameters
-
int switchNumber: number of switch
- Returns
- bool: True if on, False if off, None on error
The documentation for this class was generated from the following file:
- hardware/switches/ok_fpga/ok_fpga_switch.py
